A Primer on Refrigerants

  • By Josh Morphew
  • 19 Jun, 2017

Freon®, Puron® and more

As a facility or building manager, you face numerous decisions daily. Some of those may involve repair or replacement decisions for air conditioning or refrigeration equipment. Cooling technology is evolving to meet environmental standards and these changes could impact your decisions. In this article, we will discuss changes in refrigerant technology and their implications to daily operations.

Say Goodbye to R-22

Over the last several decades, the term Freon has been used ubiquitously to describe refrigerant used in refrigeration and cooling systems, much like Coke may be used as a catch all for soft drinks.

 In reality, Freon is a registered trademark of The Chemours Company which brands several halocarbon products with this name including R-22, one of the most common refrigerant products. Because these refrigerants have been determined to deplete the ozone layer, the EPA mandated their elimination by 2020.

Say Hello to R-410A

As a result, manufacturers have developed non-ozone depleting refrigerants using fluorine based chemicals instead. It is commonly known as R-410A and has been trademarked by several companies under different names including Puron, Foran 410A, Genetron R410A and others.

How the transition impacts your business

Since 2010, manufacturers have been ramping up production of equipment using R410A refrigerant and phasing out R-22 based equipment. As a result, if you have a 9 year old compressor or evaporator that needs to be replaced, it is unlikely there will be a match.

 Because R410A equipment is not interchangeable with R-22 based equipment, you will likely need to replace the entire unit.

Some customers have asked if they can just top off their R-22 equipment with R410A. The reality is the two refrigerants are very different and not compatible.

 When you replace R-22 equipment with R410A equipment, it is important to follow the manufacturer guidelines for refrigerant usage. Really. There are some differences in how R410A is produced and if you use the wrong type, you could void your warranty.

When to start budgeting for replacing R-22 units

If you haven’t yet started budgeting for the replacement of R-22 based equipment, this is probably a good time to begin allocating funds for future use. Most R-22 equipment has passed the mid-point of life expectancy. 10 years ago, you could have extended the life of that unit by changing compressors, evaporators or even plugging leaks and re-charging the unit with R-22. Those options are all pretty much gone today, leaving you with the need for a full replacement system.

It isn’t all gloom and doom though. Our customers have found an offset in operating expense thanks to the higher efficiency of newer equipment. Many were also able to capture a rebate from their utility company.

Need help planning for future equipment replacement?

While equipment break downs can’t be fully predicted, an inspection of older equipment can help identify potential issues and estimate the remaining life of equipment. Combine that with quotes for replacement equipment and you can make decisions in advance about budgeting and timing. The Baxter Commercial Services team can help with inspections and quotes for any of your cooling units. Contact us today to learn more.
